Product Highlights
-
Simultaneous charging: Allow simultaneous charging via 1 USB-A and 3 USB-C ports.
-
Worldwide compatibility: Universal US, UK, EU & Au plugs and versatile AC sockets are compatible travlling in over 200 countries around the world.
-
100W charging laptops: Powerful 100W supports fast charging lap tops and other power-hungered devices.
-
Extra protection: A spare 10A fuse for immediate replacement to provide extra protection.
-
Intelligent voltage conversion: Intelligent voltage conversion from different usges anywhere in the world.
-
Advanced GaN technology: Make this charger more portable to carry in the luggage.
-
Multiple safety protections: Safeguard your devices with short-circuit, overvoltage, overcurrent & overheating protection.
Specifications
-
Model: PA-TA09A
-
Charging protocols: PD3.0, QC4+, FCP, SCP, AFC, PPS, BC1-2
-
Rating: 100-250V~10A Max, 2500W Max
-
Single port output mode:
-
USB-3(C) Output: (100W Max) 5V 3A / 9V 3A / 15V 3A / 20V 5A
-
USB-4(C) Output: (100W Max) 5V 3A / 9V 3A / 15V 3A / 20V 5A
-
USB-2(C) Output: (18W Max) 5V 3A / 9V 2A / 12V 1.5A
-
USB-1(A) Output: (18W Max) 5V 3A / 9V 2A / 12V 1.5A
-
Combined output mode:
-
USB-3(C)+4(C) mode:
-
USB-4(C): (65W Max) 5V 3A / 9V 3A / 15V 3A / 20V 3.25A
-
USB-3(C): (35W Max) 5V 3A / 9V 3A / 15V 2.33A / 20V 1.75A
-
USB-2(C)+3(C)+4(C) mode:
-
USB-4(C): (65W Max) 5V 3A / 9V 3A / 15V 3A / 20V 3.25A
-
USB-3(C): (20W Max) 5V 3A / 9V 2.22A / 12V 1.67A
-
USB-2(C): (18W Max) 5V 3A / 9V 2A / 12V 1.5A
-
USB-2(C)+3(C)+4(C)+1(A) mode:
-
USB-4(C): (65W Max) 5V 3A / 9V 3A / 15V 3A / 20V 3.25A
-
USB-3(C): (20W Max) 5V 3A / 9V 2.22A / 12V 1.67A
-
USB-2(C)+1(A): 5V 3A
-
Total DC Output: 100W
-
Dimensions: 50 x 53.5 x 93mm / 1.97″ x 2.11″ x 3.66″
-
Weight: 283g / 9.98oz
